37KW Sundyne LMV 322 Replacement High Speed Centrifugal Pumps 4.0MPa

Brand Name:	Sunstrand
Model Number:	LMV-322
MOQ:	1
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	10set/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

IOS9001/IOS9002/CUTR

Product Name:

Sundyne LMV 322 Replacement

Max Suction Pressure:

4.0MPa

Feature:

Sundyne Compatible

Max Motor Power:

37KW

Operating Temperature:

-130°C To +260°C (-200°F To +500°F)

Appliction:

Liquid Transfer

Max. Flow Rate:

Up To 85 M³/h (375 GPM)

Rated Output Speed:

Up To 9,000 RPM

Packaging Details:

Wooden Case

Supply Ability:

10set/month

Highlight:

Sundyne LMV 322 Replacement Pumps

37KW High Speed Centrifugal Pumps

4.0MPa High Speed Centrifugal Pumps

Product Description

Sundyne LMV 322 Replacement High Speed Centrifugal Pumps

LMV 322 High Speed Integrally Geared Pumps Vertical Centrifugal Pump For Liquid Transfer

Product Introduction

In demanding oil refining, petrochemical processing, and upstream gas treatment industries, sourcing a reliable Sundyne LMV 322 replacement for low-flow, high-head process configurations is a critical priority for reliability engineers. Engineered in strict compliance with the API 610 (OH6 configuration) standard, these vertical, integrally geared high speed centrifugal pumps offer a seamless, drop-in alternative to legacy OEM installations without requiring costly infrastructure modifications.

Unscheduled downtime in continuous process loops can result in severe financial losses. To mitigate this risk, our line of Sundyne alternatives features substantial localized upgrades in gearbox transmission efficiency, impeller dynamic balancing, and computational fluid dynamics (CFD) hydraulic design. Utilizing a precision-engineered internal speed-increasing gearbox, these high speed centrifugal pumps for LMV 322 replacement deliver exceptional total dynamic head (TDH) while maintaining a minimal Net Positive Suction Head required (NPSHr). This allows plant operators to drastically lower capital expenditure (CAPEX) and operational lifecycle costs without altering existing process piping layout or suction/discharge configurations.

Specifications

To assist EPC contractors, design institutes, and rotating equipment engineers with precise cross-referencing and selection, the technical parameters below outline how our Sundyne LMV 322 equivalent pumps match or exceed premium international standards:

Technical Parameters	Specifications & Performance Data
Compliance Standard	Full compliance with API 610 (Latest Edition, OH6 Class)
Direct Replacement For	Sundyne LMV-322 / LMV-322 vertical inline high speed pump
Max. Flow Rate	Up to 85 m³/h (375 GPM)
Max. Total Dynamic Head (TDH)	Up to 914 m (3,000 ft)
Max. Allowable Working Pressure (MAWP)	Up to 10.0 MPa (1440 psi)
Process Temperature Range	-130°C to +260°C (-200°F to +500°F)
Rated Output Speed	Up to 9,000 RPM (via internal gearing or VFD control)
Materials of Construction (MOC)	API 610 Material Classes: S-5, S-6, C-6, A-8 (316SS, Duplex, Hastelloy)
Shaft Sealing System	API 682 compliant single/dual cartridge mechanical seals

Product Performance and Cutaway

Technical Advantages (Why Choose Our Replacement Solution)

100% Dimensional & Hydraulic Interchangeability: Suction/discharge centerline-to-centerline dimensions, foundation bolt holes, and flange pressure ratings are identical to the OEM, allowing for zero-piping-modification field changeouts.
Optimized Lead Times & Supply Chain Resilience: Free from prolonged multinational logistical backlogs, our Sundyne pump replacement lifecycle cuts lead times by over 50%. We maintain dedicated safety stock for critical rotodynamic components (high-speed shafts, pinions, and inducer stages).
Rigorous API 610 Verification: Every casing undergoes hydrostatic testing at 1.5 times the MAWP. Impellers undergo ISO 1940 G1.0 ultra-precision dynamic balancing, and every unit undergoes rigorous string testing on our certified full-performance test beds prior to dispatch.
Advanced Anti-Cavitation Hydraulics: To resolve cavitation vulnerabilities under volatile process conditions, we re-engineered the inducer geometry, significantly lower the Net Positive Suction Head available (NPSHa) threshold.

Typical Applications

Petroleum Refining & Petrochemical Processing: Hydroprocessing units, fluid catalytic cracking (FCC), light hydrocarbon reflux, and high-pressure wash water/charge services.
Fine Chemical & Coal Gasification: High-pressure transfer of hazardous or volatile chemical media like acids, alkalis, methanol, and anhydrous ammonia where zero-leakage and high head are non-negotiable.
Fertilizer & Gas Treatment: LNG receiving terminals, amine wash column reflux, and high-pressure urea condensate injection loops.

Product Packaging

One LMV322 High-Speed Vertical Centrifugal Pump
User manual and installation instructions
Safety instructions and warnings

Shipping Details

Shipping Time	Ships within 6 months
Shipping Weight	75 kgs
Shipping Dimensions	12080100cm (depend each pump)
Shipping Carrier	UPS or FedEx or Cargo
Shipping Options	Standard or expedited

FAQ

Q1: Can your high speed centrifugal pumps truly achieve seamless field replacement for an existing Sundyne LMV 322? How is quality verified?

A1: Yes, absolutely. Our equipment provides an identical hydraulic footprint and identical H-Q performance curves compared to the original Sundyne LMV 322. For quality assurance, our manufacturing facility adheres strictly to API 610 and API 682 protocols. Every replacement pump is delivered with a comprehensive quality documentation package, including Non-Destructive Testing (NDT) reports, Material Test Reports (MTRs), dynamic balancing logs, and certified hydrostatic/hydraulic performance test curves to guarantee safe, long-term operation in explosive, high-pressure hazardous areas.

Q2: What are the economic and logistical benefits of choosing your aftermarket solutions over an OEM LMV 322 asset or OEM spares?

A2: End-users frequently grapple with exorbitant OEM markup pricing and excessive turnaround times. Sourcing original equipment often introduces months of lead time, exacerbating the risk of prolonged plant downtime. Choosing our Sundyne replacement high speed pumps lowers your upfront CAPEX by approximately 30% to 50%. Backed by an agile manufacturing supply chain, we offer expedited dispatch for both turnkey pump assemblies and critical turnaround components, minimizing your total cost of ownership (TCO).

Q3: How interchangeable are the internal components for routine maintenance and warehouse standardization?

A3: Maintainability was a foundational criteria when developing this Sundyne replacement pump. Internal speed-increasing gears, high-speed bearings, and API-compliant cartridge mechanical seals are machined to strict dimensional tolerances. This means you can either deploy our complete pump assembly as a drop-in replacement for aged assets, or utilize our high-precision rotating components as interchangeable aftermarket spares within your existing fleet of Sundyne pumps to optimize inventory overhead.
